The HM-mat is an electrically heated mat designed to prevent snow and ice accumulation around the home or facility, such as on driveway, walkways and stairs and so on.
Brand:
HuanruiPower Ouput:
300W/m2Min. Installation Temperature:
5°CRated Voltage:
230,400VOuter Jacket:
PVCOuter dimensions:
6.5mmInsulation material:
Fluoropolymer or XLPECable structure:
Twin conductorHeating element size:
1.7m-20m (length)*0.6m (width)Bending radius:
38mmJacket optional:
XLPO(with higher permitted temperature in short period-220°C) for HM-mat(R)Shield:
Aluminum-plastic tape or tinned copper wiresMax. rated temperature:
105°CCold lead:
6m length and requiredCertifications:
CEIn winter; when the accumulated snow on walkways, parking garage, loading ramps, stairways and other areas, it will bring problem to people's life. Electric snow melting systems can keep walkways, parking garage, loading ramps, stairways and other areas free of snow and ice to help prevent slip hazards. Electric snow melting systems provide surface snow melting and anti-icing for concrete surfaces and pavers.
Product advantages
1.Durable and strong structure
2.High water-proofness. IP68
3.Long working life
4.25years warranty
5.Small size ,no increase in floor thickness
6.100% screened with Zero EMF
7.100% tested before delivery
8.Free of maintenance
Features
• Single point connection
• Robust, efficient, and safe
• Easy and flexible installation
• 10-year limited warranty against manufacturing defects
• Two conductors
• Emits zero EMF (electromagnetic fields)
• Durable structure
Applications
Installation of the HM-mat snow melting system provides a permanent solution to the problems caused by cold weather when snow and ice accumulation. It can be used both outdoor and indoor environment.
• Ideal for driveways, parking lots, sidewalks, stairs, ramps, bridges and many other applications.
• For used under concrete, asphalt, paver or stone and ceramic or stone tile.
• Roof & gutter de-icing.
• Subfloor energy storage heating.
The power output of per square meter can be adjusted, for example 400W/m.
Electric Underfloor Heating Mat HRWT3.2. With twisted structure, the mat is flexible and easy to install.
Learn More
Heating Thermostat User Manual Many thanks for your selection of our products and services, and also for your trust and support to us. Features Appearance (1) Standard total Size is 86*86mm (2) Touch buttons to make simple operation (3) The visible thickness above the wall is only 15mm86mm (4) hidden box and 60mm European box (5) Display size : 64*64mm (6) Color:white,black Functions (A) Including built-in sensor and external sensor (B) 0.5°C accuracy keeps temperature within the level you set. (C) Children lock to prevent misoperation by children (D) Data memory when power is off. (E) Holiday mode make you enjoy more comfortable temperature in holiday (F) The temperature of external sensor can be checked Product Specifications ☆ Power: 90-240Vac 50/60HZ ☆ Range of temperature display: 0~40°C ☆ Max. control accuracy: 0.5°C ☆ Probe sensor: NTC(10k)1% ☆ Contact capacity: 3A/250V(WW);16A/250V(WE) ☆ Output: Switch relay ☆ Limit temperature range: 0~70°C ☆ Insulating condition: Normal environment ☆ Default setting temperature range：5~35°C ☆ Size(mm)：86*86*27 Before wiring and installation 1.Read these instructions carefully. Failure to follow them could damage the product or cause a hazardous condition. 2.Check the ratings given in the instructions and on the product to make sure the produce is suitable for your application. 3.Installer must be a trained experienced service technician. 4.After installation is complete.check out produce operation as provided in these instructions CAUTION Electrical shock or equipment Damage Hazard. or short equipment circuitry. Disconnect power supply before installation Sensor fault display:please choose correct working way of built-in and external sensor, if choose wrongly or sensor fault (breakdown), “E1” or “E2” will be displayed on the screen. Thermostat will stop heating until the fault is eliminated Warranty： We offer the warranty of 18 months, from the sales day. The products of our company can have lifetime warranty ,if it is not the quality problems, or beyond the warranty period, we will charge for the after-sale service
Learn More
HRSHTV heating cable is designed for both roof and gutter or ground applications. HRSHTV is a twin conductor heating cable for easy installation with zero EMF.
Learn More
RSR self-regulating heating cables provide the most versatility in heat trace designs and applications.
Learn More
RDC series connection constant wattage heating cable use the core conductor as the heating element, when the core conductor connect to power supply, the core conductor will send out joule heat, same as they are of the entire cable length, the heating value of each unit is the same.
Learn More
The snow melting mat starts to work quickly, it is used for warming in multiple areas; it is also suitable for environments of strict requirements. Pre-assembled with a plug ready for use, easy to connect and flexible to move.
Learn More
HWSR self-regulating heating cable is highly efficient both to prevent freezing and to maintain temperature for hot water supply pipes.
Learn More
HRDVCM underfloor heating mat uses a twin conductor heating cable for easy installation, and mat is designed for installation into thin adhesive beds, leveling compounds or thin screed beds beneath tiled and wooden floor.
Learn More
